Collect

Data collection is one of the most common tasks that virtual assistants perform. The Collect action enables you to ask questions to users and efficiently collect answers.

Collect is similar to using web forms. You define the field name and the type for each question and Collect will render conversational flow to ask the user the questions.

The answers are collected in the Assistant's memory and sent in the request parameters on every Autopilot webhook.

  • Collect Properties
  • Questions
  • Validate

Collect properties

Property Description Required
name

A unique string that describes the data being collected. No spaces are allowed.

Yes
questions

An array of questions to ask the user.

Yes
on_complete

The action to execute when the questionnaire is successfully completed.

It can take a redirect action with a task or a URL (see request params).

Yes

Question properties

Property Description Required
question

The question to ask. It can be a { say } action.

Yes
name

The name of the field collected. This must be unique within the questionnaire. No spaces are allowed.

Yes
type

The field type of the questions being collected. This can be a built-in field type or a custom field type.

See built-in field types for more information.

No. If no type is provided free-form input will be collected.
voice_digits

Provide the option to use DTMF in addition to speech for the input if they are interacting with your bot over the voice channel. This property will be ignored on other channels. More details below.

No.
{
	"actions": [
		{
			"collect": {
				"name": "collect_comments",
				"questions": [
					{
						"question": "Please let us know any comments or feedback on your recent purchase",
						"name": "comments"
					}
				],
				"on_complete": {
					"redirect": "https://example.com/collect"
				}
			}
		}
	]
}

Questions

Example 1: Single free-form question

Free-form questions that are going to receive any type of input, do not need to specify any Type.

{
	"actions": [
		{
			"collect": {
				"name": "collect_comments",
				"questions": [
					{
						"question": "Please let us know any comments or feedback on your recent purchase",
						"name": "comments"
					}
				],
				"on_complete": {
					"redirect": "https://example.com/collect"
				}
			}
		}
	]
}

The answers come in the Memory parameter with a JSON containing:

{
	"twilio": {
		"collected_data": {
			"collect_comments": {
				"status": "complete",
				"date_started": "2018-09-10T10:42:00Z",
				"date_completed": "2018-09-10T10:42:00Z",
				"answers": {
					"comments": {
						"answer": "I love the product! thanks so much!",
						"filled": true,
						"attempts": 1,
						"confirmed": false
					}
				}
			}
		}
	}
}

Example 2: Single question: what's your name?

{
	"actions": [
		{
			"collect": {
				"name": "ask_first_name",
				"questions": [
					{
						"question": "Hi! What's your name",
						"name": "first_name",
						"type": "Twilio.FIRST_NAME"
					}
				],
				"on_complete": {
					"redirect": "https://example.com/collect"
				}
			}
		}
	]
}

The answers come in the Memory parameter with a JSON containing:

{
	"twilio": {
		"collected_data": {
			"ask_first_name": {
				"status": "complete",
				"date_started": "2018-09-10T10:42:00Z",
				"date_completed": "2018-09-10T10:42:00Z",
				"answers": {
					"first_name": {
						"answer": "Robert",
						"type": "Twilio.FIRST_NAME",
						"filled": true,
						"attempts": 1,
						"confirmed": false
					}
				}
			}
		}
	}
}

Example 3: Multiple questions

The questions will be asked sequentially.

{
	"actions": [
		{
			"collect": {
				"name": "travel_questions",
				"questions": [
					{
						"question": "Do you like traveling?",
						"name": "likes_traveling",
						"type": "Twilio.YES_NO"
					},
					{
						"question":"What's your favorite city?",
						"name": "favorite_city",
						"type": "Twilio.CITY"
					}
				],
				"on_complete": {
					"redirect": "https://example.com/collect"
				}
			}
		}
	]
}

The answers come in the Memory parameter with a JSON containing:

{
	"twilio": {
		"collected_data": {
			"travel_questions": {
				"status": "complete",
				"date_started": "2018-09-10T10:42:00Z",
				"date_completed": "2018-09-10T10:42:00Z",
				"answers": {
					"likes_traveling": {
						"type": "Twilio.YES_NO",
						"answer": "Yes",
						"filled": true,
						"attempts": 1,
						"confirmed": false
					},
					"favorite_city": {
						"answer": "San Francisco",
						"type": "Twilio.CITY",
						"filled": true,
						"attempts": 1,
						"confirmed": false
					}
				}
			}
		}
	}
}

Validate

Collect enables you to validate the user input with the Validate instruction.

Validate property Description Default
allowed_values A list of allowed values

If no list of values is specified, Validate will verify that the value is a valid type for the specified field type.

For example, if the field is Twilio.DATE, Validate will verify that the provided value is a valid date.

webhook A webhook to validate the value being collected. Useful when validating fields like order numbers or available dates that can only be validated against your business logic

If no webhook is specified, Validate will verify that the value is a valid type for the specified field type.

If both allowed values and webhook are specified, only allowed values is considered.

See Example 6.

on_failure The messages when the input is invalid.

By default, the on_failure messages are defined in the Stylesheet. It can be overridden by defining on_failure messages in the collect.

The on_failure action is defined in the Defaults. It can be overridden by defining the on_failure message in the collect.

on_success The message when the question is answered successfully. By default, the on_success message is defined in the Stylesheet. It can be overridden by defining on_success message in the collect.
max_attempts How many times it should ask the user the question By default, max_attempts is defined in the Stylesheet. It can be overridden by defining max_attempts in the collect.

Collect Validate Webhook

The request parameters

The Collect Validate webhook has all the Standard Autopilot Parameters except the two parameters Field_{field-name}_Value and Field_{field-name}_Type and the Collect Validate specific parameters defined below:

Parameter

Description

Example

CollectName

The name of the Collect

CollectName=travel_questions

CollectDateStarted

The timestamp when the Collect was started.

CollectDateStarted=2018-09-10T10:42:00Z

CollectStatus

The status of the Collect

CollectStatus=in-progress

ValidateFieldName

The name of the field to be validated

ValidateFieldName=trip_start

ValidateFieldType

The type of the field to be validated

ValidateFieldType=Twilio.CITY

ValidateFieldAnswer

The value to be validated

ValidateFieldAnswer=San Francisco

Expected response

Autopilot expects the following JSON response when the value is valid:

{
   "valid" : true
}

Autopilot expects the following JSON response when the value is not valid:

{
   "valid" : false
}

Example 4: Multiple questions with validate

{
	"actions": [
		{
			"collect": {
				"name": "travel_questions",
				"questions": [
					{
						"question": "Where would you like to start your Trip? New York or San Francisco",
						"name": "trip_start",
						"type": "Twilio.CITY",
						"validate": {
							"allowed_values": {
								"list": [
									"New York",
									"San Francisco"
								]
							},
							"on_failure": {
								"messages": [
									{
										"say": "Sorry, that's not a valid start city."
									},
									{
										"say": "Hmm, I'm not understanding. It can be San Francisco or New york."
									}
								],
								"repeat_question": true
							},
							"on_success": {
								"say": "Great, we've got your starting city"
							},
							"max_attempts": {
								"redirect": "task://having-trouble",
								"num_attempts": 3
							}
						}
					},
					{
						"question": "Would you like to be on our January, June or September trip?",
						"name": "trip_month",
						"type": "Twilio.Month",
						"validate": {
							"allowed_values": {
								"list": [
									"January",
									"June",
									"September"
								]
							},
							"on_failure": {
								"messages": [
									{
										"say": "Sorry, that's valid month"
									},
									{
										"say": "Hmm, I'm not understanding. It can be January, June, and September"
									}
								],
								"repeat_question": true
							},
							"on_success": {
								"say": "Great, we've got your month"
							},
							"max_attempts": {
								"redirect": "task://having-trouble",
								"num_attempts": 3
							}
						}
					}
				],
				"on_complete": {
					"redirect": "https://example.com/collect"
				}
			}
		}
	]
}

Valid answers come in the Memory parameter with a JSON containing:

{
	"twilio": {
		"collected_data": {
			"travel_questions": {
				"status": "complete",
				"date_started": "2018-09-10T10:42:00Z",
				"date_completed": "2018-09-10T10:42:00Z",
				"answers": {
					"trip_start": {
						"type": "Twilio.CITY",
						"answer": "San Francisco",
						"filled": true,
						"attempts": 1,
						"confirmed": false
					},
					"trip_month": {
						"answer": "January",
						"type": "Twilio.MONTH",
						"filled": true,
						"attempts": 1,
						"confirmed": false
					}
				}
			}
		}
	}
}

Invalid answers would look like this:

{
	"twilio": {
		"collected_data": {
			"travel_questions": {
				"status": "complete",
				"date_started": "2018-09-10T10:42:00Z",
				"date_completed": "2018-09-10T10:42:00Z",
				"answers": {
					"trip_start": {
						"type": "Twilio.CITY",
						"error":{
                          "error_message":"Invalid Value",
                          "value":"donuts"
                       }
,
						"filled": true,
						"attempts": 1,
						"confirmed": false
					},
					"trip_month": {
						"error":{
                          "error_message":"Invalid Value",
                          "value":"I habe no idea"
                       },
						"type": "Twilio.MONTH",
						"filled": true,
						"attempts": 1,
						"confirmed": false
					}
				}
			}
		}
	}
}

Example 5: Single question without validation or optional

{
	"actions": [
		{
			"collect": {
				"name": "ask_first_name",
				"questions": [
					{
						"question": "Hi! What's your name",
						"name": "first_name",
						"type": "Twilio.FIRST_NAME",
						"validate": false,
					}
				],
				"on_complete": {
					"redirect": "https://example.com/collect"
				}
			}
		}
	]
}

Example 6: Single question validation webhook

{
    "actions": [
        {
            "collect": {
                "name": "travel_questions",
                "questions": [
                    {
                        "question": "Where would you like to start your Trip?",
                        "name": "trip_start",
                        "type": "Twilio.CITY",
                        "validate": {
                            "on_failure": {
                                "messages": [
                                    {
                                        "say": "Sorry, that's not a valid start city."
                                    },
                                    {
                                        "say": "Hmm, I'm not understanding. It can be San Francisco or New york."
                                    }
                                ],
                                "repeat_question": true
                            },
                            "webhook": {
                                "url":"https://example.com/validateTripStart",
                                "method":"POST"
                            },
                            "on_success": {
                                "say": "Great, we've got your starting city"
                            },
                            "max_attempts": {
                                "redirect": "task://say",
                                "num_attempts": 3
                            }
                        }
                    }
                ],
                "on_complete": {
                    "redirect": "https://example.com/collect"
                }
            }
        }
    ]
}

DTMF

Collect also lets you provide users the option to answer questions with DTMF inputs using the voice_digits property if they are using your bot on the voice channel. This can be useful if you're building an IVR with Autopilot.

voice_digits has the following properties:

Property name Description Optional Default value Allowed values
num_digits The number of DTMF inputs you expect from the user. Yes unlimited positive integers
finish_on_key The key the user should press to submit their input. If not provided, Autopilot will automatically move to the next Action after 5 seconds Yes # 0-9, #, *, and '' (the empty string)
mapping The mapping of DTMF inputs to field values. If not used, Autopilot will provide the raw DTMF input to your application. N/A A JSON object mapping DTMF values to expected inputs.

Input validation when using mapping and type properties at the same time

Autopilot will only use type to validate speech inputs and not DTMF inputs. If a valid mapping exists for the DTMF input, it will send back the associated value to your application. If no mapping exists, it will send back the raw DTMF input instead.

Example 7: Collect a yes or no response

{
	"actions": [
		{
			"collect": {
				"name": "collect_dtmf_yes_no",
				"questions": [
					{
						"question": "Are you a customer? Press or say 1 if you are and 2 if you are not a customer.",
						"name": "customer",
						"type": "Twilio.YES_NO",
						"voice_digits": {
							"num_digits": 1,
							"finish_on_key": "#",
							"mapping": {
								"1": "Yes",
								"2": "No"
							}
						}
					}
				],
				"on_complete": {
					"redirect": {
						"uri": "https://example.com/collect",
						"method": "POST"
					}
				}
			}
		}
	]
}

Example 8: Collect a number by limiting the number of digits

{
	"actions": [
		{
			"collect": {
				"name": "collect_zip_5_digits",
				"questions": [
					{
						"question": "Hi! Please say or type your zip code.",
						"name": "zip_code",
						"type": "Twilio.NUMBER",
						"voice_digits": {
							"num_digits": 5
						}
					}
				],
				"on_complete": {
					"redirect": {
						"uri": "https://example.com/collect",
						"method": "POST"
					}
				}
			}
		}
	]
}

Example 9: Collect a number with the finishOnKey

{
	"actions": [
		{
			"collect": {
				"name": "collect_zip_finish_on_key",
				"questions": [
					{
						"question": "Hi! Please say or type in your zip code.",
						"name": "zip_code",
						"type": "Twilio.NUMBER",
						"voice_digits": {
							"finish_on_key": "#"
						}
					}
				],
				"on_complete": {
					"redirect": {
						"uri": "https://example.com/collect",
						"method": "POST"
					}
				}
			}
		}
	]
}

Prefill

Collect's Prefill feature intelligently skips questions asking for information the user has already provided in the utterance invoking the task. Prefill can be enabled separately on each question by setting the prefill attribute to the Field Name expected. Note that the Task being triggered should be trained with adequate samples containing the Field Names for Prefill to work.

Example 10: Prefill

{
	"actions": [
		{
			"collect": {
				"name": "book_appointment",
				"questions": [
					{
						"question": "What date?",
						"name": "appt_date",
						"type": "Twilio.DATE",
						"prefill": "Date"
					},
					{
						"question":"What time?",
						"name": "appt_time",
						"type": "Twilio.TIME",
						"prefill": "Time"
					}
				],
				"on_complete": {
					"redirect": "https://example.com/collect"
				}
			}
		}
	]
}

Scenarios

1. I would like to book an appointment on {Date} at {Time}

Since both Fields are present in the initial utterance, Collect will skip both questions and move to on_complete.

2. I would like to book an appointment on {Date}.

Collect will ask the first question but skip the second question before moving to on_complete.

3. I would like to book an appointment.

Collect will ask both questions before moving to on_complete.

Rate this page:

Need some help?

We all do sometimes; code is hard. Get help now from our support team, or lean on the wisdom of the crowd browsing the Twilio tag on Stack Overflow.
